The RISC-V Exchange hosts the hardware, software, services, and learning offerings in the RISC-V community. Browse the list or search for an offering below.

RCHD-PF System on Module

Organization: Conclusive Engineering Sp. z o.o.

Orchid System on Module featuring Microchip PolarFire® SoC FPGA featuring 667 MHz 5 core RISC-V processor, 23 K to 254 K logic elements FPGA. Use Cases include Operational Technology and Industrial Control Systems, Imaging and Video Processing, Internet of Things (IoT), Industrial Automation, Artificial Intelligence/Machine Learning (AI/ML), Aerospace and Defense, Wireline Access Networks, Cellular Infrastructure. Features 5 core RISC-V 667 MHz, FPGA up to 254K logic elements, up to 8GB RAM, up to 64GB eMMC, High-speed IO, Numerous buses and interfaces, Real-time signal processing


Conclusive Engineering RCHD-PF PolarFire System on Module with Evaluation Board

Organization: Conclusive Engineering

Conclusive Engineering “Orchid” RCHD-PF is a System on Module powered by the Microchip PolarFire® SoC. It has a 5-core 667 MHz RISC-V processor, and an FPGA with up to 254K logic elements. RCHD-PF supports the whole range of Microchip's PolarFire SoCs based on the FCVG 484 package. 30% smaller than a credit card, it can power over 30 Watts of peripherals directly, with standard load from SoC at around 6W. Connectivity happens through 4 surface mounted connectors from HIROSE, readily available on market. Pinout is open source. RCHD-PF comes with an evaluation board that offers SFP+, Ethernet, USB, HDMI, CAN rail, two M.2 connectors, wireless, and more. It also has a PCIe edge connector that lets you use the setup as an endpoint device. Something's missing? No problem - we can deliver a custom daughterboard that's made to fit your needs. Conclusive Engineering fulfills the requirements of TAA Federal Certification, and Orchid and its evaluation board are manufactured locally in the European Union, in a secure facility. We provide constant software support for the board, including commits to mainline Linux and FreeBSD kernels. Since we fully own the board's IP, we can offer complete customization on all levels - from PCB design, kernel, drivers, bare metal, to high level applications - and very low volume custom production runs.

License Type: Mixed


Updates and edits to existing entries, as well as contribution of new entries, are welcome! Please submit your inputs here.
