Espressif ESP32-C6-DevKitC-1
Organization: Espressif Systems
ESP32-C6-DevKitC-1 is an entry-level development board based on ESP32-C6-WROOM-1(U), a general-purpose module with a 8 MB SPI flash. This board integrates complete Wi-Fi, Bluetooth LE, Zigbee, and Thread functions. Uses Cases: Smart home, Industrial automation, Health care, Consumer electronics, Generic low-power loT sensor hubs, Generic low-power loT data loggers. Features A high-performance (HP) 32-bit RISC-V processor, which can be clocked up to 160 MHz, and a low-power (LP) 32-bit RISC-V processor, which can be clocked up to 20 MHz. 320 KB ROM, 512 KB SRAM, SPI/Dual SPI/Quad SPI/QPI supports multiple flash. Connectivity: 2.4 GHz Wi-FI 802.11b/g/n/ax, Bluetooth 5 (LE) with Long Range support, IEEE Standard 802.15.4-2015, supports Thread and Zigbee, Wi-Fi and Bluetooth LE mesh support. Peripherals: GPIOs, SPI, UART, I2C, I2S. RMT. TWAI. PWM, SDIO. Motor Control PWM, ADC, Temperature sensor. Security features include RSA-3072-based secure boot, AES-128/256-XTS-based flash encryption, Digital signature peripheral and the HMAC peripheral, Trusted execution environment (TEE) controller and access permission management (APM), Random Number Generator (RNG), Hardware acceleration support for cryptographic algorithms
